ID Technology 252 - Page 140

Model 252
Label Printer/Applicator
Operators/Technical Manual
24
Figure 15: Assembly View, ID100001 Electronics Assembly
TOUCHSCREEN
DISPLAY
FRONT VIEW
SYSTEM STATUS
OUTPUT CONNECTOR
(OPTIONAL)
PRINT ENGINE
COMMUNICATION
CONNECTOR
ETHERNET
COMMUNICATION
CONNECTOR
(OPTIONAL)
PEC1/PEC2/3 STAGE
BEACON CONNECTOR (2)
BACK VIEW
