1
1
2
2
3
3
4
4
A A
B B
C C
D D
SHEET
5
OF
5
DRAWN
CHECKED
QA
MFG
APPROVED
DWG NO
TITLE
SIZE
SCALE
REV
2051 FRANKLIN DR.
FORT WORTH, TX 76106
.00
02
.000
ANGLE
1
005
STANDARD
TOLERANCE
clari
10/20/2011
ID100070
PRINTER APPLICATOR,252E RH
C
PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
1 2 60224 WASHER,DIRECTIONAL .8
OD X .25 ID
2
1
62015-08 COLLAR, GUIDE 1"
3 1 62030-16 ROLL,IDLER
4
2 62031 SHAFT,IDLER
5 2 62034 ROLL,SPACER
6
1
62120 FILTER REGULATOR
ASSEMBLY
7 2 62162 BLOCK,TRUNION
8
1
62180 TUBE,AIR ASSIST
9 2
92141A056 WASHER,PLAIN 3/4" S.S.
10 2 93303A113 WASHER,ARAMID FIBER 1
x 1-1/2 x .062
11 1 CF24 12 CABLE GLAND,
RECTANGULAR ROTEX
12
1
ID100001 ASSY,252 ELECTRONIC
MODULE
13
1
ID100009 NAMEPLATE,252 RH
14 1 ID100011 BRACKET,AIR ASSIST
15 1
ID100013
ASSY,UNWIND RH 14"
16
1
ID100021 ASSY,REWIND 252RH 14"
17 1 ID100035 ASSY,IDLER ROLLER
18
1
ID100037 ASSY,PNEUMATICS 252RH
19 1 ID100071 PLATE, BASE 252E
PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
20 1 ID100072 ASSY, ENCLOSURE 252E RH
21 2 M20
Plain Washer
22 2 M20 Spring Washer
23 2 M20x50
Hex-Head Bolt
24 2
M4
Plain washer
25 2 M4
Spring Washer
26
1
M4x10
Socket Head Cap Screw
27
4
M4x16 Socket Head Cap Screw
28 2 M4x25
Socket Head Cap Screw
29 2 M5x12
Socket Head Cap Screw
30
5 M5x14
Socket Head Cap Screw
31 10 M6
Plain washer
32 19 M6 Spring Washer
33 2 M6x10
Pozidriv Pan Head Screw
34 9 M6x12
Socket Head Cap Screw
35
4
M6x20 Socket Head Cap Screw
36 2 M6x40
Socket Head Cap Screw
37
4
M6x55 Socket Head Cap Screw
38 2 M6x60
Socket Head Cap Screw
To Next Page
