iDataLink maestro Rr Install Guide

ADS-RR(SR)-VW01-DS
Volkswagen golF r 2012-2013
Automotive Data Solutions Inc. © 2016
6
VEHICLE WIRE REFERENCE CHART
Wire
Description
Connector
Name
Connector
Color
Connector
Type
Position Wire Color Polarity
Wire
Location
CanH A ~ 16 pin 06 Orange/Black (DATA) OBDII connector, under driver side dash
CanL A ~ 16 pin 14 Orange/Brown (DATA) OBDII connector, under driver side dash
Warning: Factory Compass Module
If your vehicle is equipped with a factory compass module and you are installing an aftermarket radio that supplies navigation
information to the MFD of the vehicle, disconnect the factory compass module located under the headliner at the rear of the
vehicle.

iDataLink maestro Rr Specifications

General

Category	Automobile Accessories
Type	Vehicle Interface Module
Compatibility	Works with select vehicles and aftermarket radios
Features	Retains factory features
Functionality	Allows integration of aftermarket radios with factory vehicle systems
Programmability	Programmable via Weblink desktop application
Firmware Updates	Supports firmware updates through Weblink
Data Bus Support	CAN bus
Vehicle Coverage	Compatible with a wide range of makes and models
Additional Features	May include support for factory amplifiers, backup cameras, and more
Installation	Professional installation recommended
