Fluid Drain Points
1. For detailed operation, maintenance & care of the DSD SmartCAFS pump, refer to 8FG/DSD
Series HIGH Volume Pumps; Operation and Maintenance Manual (Document number 029-
0020-93-0). For Q-Series, refer to 029-0020-63-0 Muscle Pump manual.
2. Clutch Fluid Drain & Gearbox Oil Drain.
Figure 29: Gearbox (DSD Version Shown) Drain Points
