Page 81 of 116
©HALE PRODUCTS, INC. Our policy is one of continuous development. We therefore
reserve the right to amend specifications without notice or obligation.
WARNING
ALWAYS ALLOW OIL TO SETTLE PRIOR TO CHECKING LEVEL. DO NOT
OVERFILL THE
SYSTEM.
THE PROPER OIL LEVEL MUST BE MAINTAINED IN THE AIR COMPRESSOR
SYSTEM AT
ALL TIMES. LOW OIL LEVEL OR NO OIL COULD RESULT IN
EXCESSIVE COMPRESSOR
TEMPERATURE AND MAJOR DAMAGE. HIGH
OIL LEVEL COULD CAUSE THE CONTROL
SYSTEM TO MALFUNCTION OR A
DRIVE FAILURE.
11. When the system is filled to the proper level, check and clean the O-ring seal on the fill plug, then
replace the plug. DO NOT over-tighten.
12. Start the system and energize the air compressor to allow pressure to build and circulate oil
through the hoses.
WARNING
WHEN STARTING DSD SmartCAFS UNIT DURING MAINTENANCE, MAKE SURE
ALL TOOLS
AND LOOSE CLOTHING ARE KEPT AWAY FROM ROTATING
COMPONENTS. KEEP HANDS,
FACE AND ARMS AWAY FROM ROTATING
COMPONENTS WHILE SYSTEM IS OPERATING.
13. DO NOT allow the system to operate for more than 30 seconds. While the system is running
check for leaks at the oil filter, drain plug and fill plug.
14. Shut down the system and allow the air compressor oil to settle.
15. Check oil level and add oil as necessary until oil is visible in 1/2 to 3/4 range of the sight gauge
tube.
16. Shut down the system.
COOLING WATER STRAINER
The stainless steel mesh strainers prevent any solids or debris in the pump water from passing into
the heat exchanger where they can clog and lead to overheating and serious damage. They can be
easily cleaned using warm water, and/or then replaced.
WARNING
DO NOT REMOVE STRAINER CAP WHILE PUMP IS RUNNING.
The strainer should be cleaned and checked after each use or every month. The 1-1/2” NST Cap is
located on the passenger side of the apparatus.
• The stainless steel mesh basket pulls out for cleaning.
• Clean thoroughly using warm water. Replace if the screen is ripped or damaged. Order Hale p/n:
010-0670-00-0.
AIR CLEANER ELEMENT
Change the air cleaner element on the SmartCAFS System every time the engine air filter is changed.
Order Hale p/n: 010-0690-00-0.
