COMPRESSOR BELT MAINTENANCE
REMOVE BELT GUARD
To expose the belt, the belt guard, 6 screws, and hardware must be removed.
Figure 44: Belt Guard Location (DSD Shown)
ATTENTION
Proper belt tension is critical to long equipment life. A loose belt causes a knock or bang as the teeth
jump. An over tightened belt overloads the bearings and leads to premature wear or failure.
