Front-Panel LEDs
16.3.2 Evolution X3 and X5
Ta b l e 8 contains LED definitions for the Evolution X3 and X5 Satellite Routers:
Table 8. iDirect Evolution X3 and X5 LED Definitions
Label Color Definition
RX Off Receiver off or not configured
Yellow Demodulator not locked to the down
stream carrier
Flashing Yellow Demodulator locked. NCR not locked.
Green Demodulator locked. NCR locked.
TX Off Trans mitt er o f f. I f STA
TUS is green, transmitter configured off.
Yellow Transmitter enabled and muted
Green Transmitter enabled and not muted
NET Off Satellite Router off or in sleep mode if TX is yellow
Yellow Demodulator not locked to th
e down
stream carrier
Flashing Yellow Demodulator locked. NCR not locked.
Flashing Green (2 sec) Demodulator locked. NCR locked.
Flashing Green (1 sec) Network acquisition in progress
Green The Satellite Router is in the network
STATUS Off Power off, or executing DRAM test
Flashing Green DRAM test failed
Green Normal operation
Red Fault: software, hardware, confi
g
uration, or self-test
POWER Off No power or low power input
Green Valid power input detected
