iDirect Evolution X1 - Evolution X7; Table 10. Idirect Evolution X7 LED Definitions

iDirect Satellite Router Installation and Commissioning Guide 97
iDX Release 3.3
Front-Panel LEDs
16.3.4 Evolution X7
Ta b l e 1 0 contains LED definitions for the Evolution X7 Satellite Routers.
Note: LED indications and definitions are software-c
ontrolled, and may differ from
previous iDX releases. The definitions in this chapter apply to iDX Release 3.3.
Table 10. iDirect Evolution X7 LED Definitions
Label Color Definition
POWER Off No power or low power input
Green Valid power input detected
Yellow Incorrect BUC voltage selection
STATUS Off Power off or executing initial self-test
Flashing Green Self-test failed
Green Normal operation
Red Fault: software, hardware, con
f
iguration, or self-test
FAN Green All fans working
Red Failure of one or more fans
TEMP Off Satellite Router off, or initializi
ng if STATUS is not green
Green Normal operating temperature
Yellow Operating temperature near high or low threshold
Red Operating temperature exceeds high or low threshold
RX1/RX2 Off Receiver off or not configured. (RX2 not supported in iDX 3.3)
Yellow Demodulator not locked to the downstream carrier
Flashing Yellow Demodulator locked. NCR
n
ot locked.
Green Demodulator locked. NC
R locked.
Red Operating temperature exceeds high or low threshold
TX Off Transm i t te r off . If ST
A
TUS is green, transmitter configured off.
Yellow Transmitter enabled and muted
Green Transmitter enabled and not muted
NET Off Satellite Router off or in sleep mode if TX is yellow
Ye
llow Demodulator not locked to the downstream carrier
Flashing Yellow Demodulator locked. NCR
n
ot locked.
Flashing Green (2 sec) Demodulator locked. NC
R locked.
Flashing Green (1 sec) Network acquisition in progress
Green The Satellite Router is in the network
