Appendix B: Disabling the
PWM Voltage in iBuilder
The PWM voltage normally present on the TX Out port during antenna pointing may be
disabled from within iBuilder.
To Disable the PWM Voltage:
1. Apply power to th
e Satellite Router and allow it to initialize.
2. In iBuilder, right-click the remote and select Modify
Item.
The Remote Information tab
opens.
Figure 61. iBuilder Remote Information Tab: Disabling Tx PWM
