iDirect Satellite Router Installation and Commissioning Guide 23
iDX Release 3.3
Loading Packages with iSite
4.2 Loading BSP and Remote Images
After logging in to iSite, load the board support and remote image file packages on the
Satellite Router.
For Evolution X3, X5 and e8000 Series Satellite Ro
uters, two model-specific packages must be
loaded: the Linux board support package (BSP), and the remote image package. Both
packages must be loaded in order, starting with the BSP, followed by the remote image
package.
For each model type supported in iDX Release 3.3, Ta b l e 2 identifies the folder name
containing the packages and the contents of each folder for iDX R
elease 3.3. The Images
folder is in the location on the local PC created during the unzip operation.
Note: See “Connecting with Web iSite” on page41 for procedures to load Evolution
X1, X7, and e150 software packages.
To Load the BSP File:
1. Right-click the Remote element in the
iSite Tree View and select Download Package.to
open the Download Package dialog box.
2. Click the Op
en button to display the Open dialog box.
3. Navigate to the software package folders
on the local PC.
4. In the Open dialo
g box, open the folder with the applicable Satellite Router model
number in the folder name. Figure 14 illustrates an example when commissioning the X3.
5. Double-click the board suppo
rt package (.bsp file) in the Open dialog box. The selected
package file is displayed in the Download Package dialog box.
Table 2. iDX Release 3.3 Remote Software Packages by Model Type
Model Location Packages to Download
X3, X5 /Images/Remote_Evolution_X3_X5 evo_x3_x5_bsp-15.0.0.0.bsp
evo_x3_x5_rmt-15.0.0.0.pkg
e8000 Series /Images/Remote_Evolution_e8series evo_bsp-15.0.0.0.bsp
e8_rmt-15.0.0.0.pkg
X1 /Images/Remote_Evolution_X1 evo_x1_indoor_rmt-15.0.0.0.pkg
evo_x1_outdoor_rmt-15.0.0.0.pkg
X7 /Images/Remote_Evolution_X7 evo_X7_rmt-15.0.0.0.pkg
e150 /Images/Remote_Evolution_e150 evo_e150_rmt-15.0.0.0.pkg
