2 SYSTEM OVERVIEW

Embedded control Features

RS232 display connection

Digital inputs for enabling switch

DC/DC converter 5V/4A

Table 3: Integrated Computer - Speciﬁcations

2.2 Mechanical Dimensions

For mechanical dimensions, please refer to the data sheet of the ReBeL.
