page 28
Saving Data
The Data Table can be saved in CSV format and imported into
Microsoft Excel and Word.
* Check items to save in the Display Menu.
* Data may not appear correctly in Microsoft Excel depending on
the Excel settings.
1. Saving a new file
Click on File/Save As CSV to save or click the SAVE button to
select folder and filename.
2. Adding to existing CSV file
Click File/Add to Existing CSV File and select a CSV file.
The Data Table can be added to an existing file. The new data
appears to the right of the previous data.
* New data cannot be added to an open file. Close the file in
which the data is to be added.
Maximum,30.54,@,12
Minimum,-0.01,@,33
Average,14.9424242424242
Quantity,33
Std. Dev.,11.5534894702594
Number of +NG,22
1,+00.59,N,+0000.000,mm,’OK,13:57:14,2013/01/14
2,+08.29,N,+0000.000,mm,’+NG,13:57:15,2013/01/14
3,+14.84,N,+0000.000,mm,’+NG,13:57:15,2013/01/14
4,+19.41,N,+0000.000,mm,’+NG,13:57:15,2013/01/14
Saves maximum and minimum results
followed by @ and the data number.
Saves the average value, number of data,
standard deviation and number of +NG
results
Example of saved data:
Saves the data displayed in
the data table.
Copy & Paste
Click or go to File/Copy copy the Data Table to the clipboard in text
format. The copied data can be pasted into Microsoft Word and Excel.
