MAGIS COMBO V2
24
N
L
KEY:
ELB - Safety Switch
MCCB - Circuit breaker switch
With use of the mono-phase safety switch (ELB).
BUS Communica-
tion cable
Main power
of power supply
ELB
MCCB
MCCB
Cable
clamping
clip
Depending on the model, the actual appear-
ance of the unit may dier from the one shown
in the gure.
Indoor Unit
Electrical panel
M4 screw communication BUS
Electric power supply
M5 screw
M4 screw communication BUS
M4 screw supply voltage
AUDAX PRO 9 V2 - Supply voltage in mono-phase AC.
AUDAX PRO 4 and 6 V2 - Supply voltage in mono-phase AC.
10.1
11.4
1215
Fairlead
terminal
18 OUTDOOR UNIT TERMINAL BLOCK ELECTRICAL CONNECTIONS
11.4
10.1
N
L
17
13
N
L
13.1
10.1
10,1
