Immergas MAGIS COMBO V2 - Magis Combo V2; Magis Combo Plus V2 P.C.b

MAGIS COMBO V2
28
KEY:
1 - P.C.B. adjustment
2 - Vertical terminal block electrical connections (230 Vac)
3 - Horizontal terminal block electrical connections (Very low safety voltage)
A1 - Ignition board
A2 - P.C.B.
A7 - ree-relay board (optional)
A13 - System manager (optional)
A17-1 - Modbus zone 1 temp./humidity probe (optional)
A17-2 - Modbus zone 2 temp./humidity probe (optional)
A17-3 - Modbus zone 3 temp./humidity probe (optional)
A19 - Two-relay board (optional)
A22 - Interface board
A23 - Outdoor unit
A30 - Dominus (optional)
A32-1 - Zone 1 remote panel (optional)
A32-2 - Zone 2 remote panel (optional)
A32-3 - Zone 3 remote panel (optional)
T2 - Ignition transformer
