MAGIS COMBO V2
5
• e electronics of MAGIS COMBO V2 is designed to directly
manage 3 zones (one direct and two mixed), for the third mixed zone
it is necessary to provide the congurable relay interface kit code
3.015350) for both central heating and cooling operation; in this
case MAGIS COMBO V2 can be connected to zone remote panels
via Bus connections (up to 3 can be provided), or it can be connected
with simple on/o contacts (e.g. CHRONO 7) to control the room
temperature of the 3 zones. 3 humidistats or 3 Modbus temperature
and humidity sensors can be connected to control humidity;
• Possibility of setting 3 climatic curves for hot and 3 climatic curves
for cold (for the 3 zones), on the electronics of the hydronic module,
no need to provide for the system manager;
• Possibility to set on each zone if the zone is only hot, hot/cold, only
cold (dehumidication included, with dew point calculation);
• To manage the dehumidiers, it is necessary to insert in the indoor
wall-hung unit a 2 relay board kit (optional), to control 2 dehumid-
iers (the third one is controlled by the congurable relay interface
kit code 3.015350); the kit allows the dehumidiers to be activated
through a potential-free contact;
• It includes a 230 V output to control summer/winter diverter valves
in heating systems with fan coil cold/radiant panels; switching occurs
with the change of mode (summer/winter) from the control panel;
• e electronic of MAGIS COMBO V2 manages the anti-legionella
function;
• Input to force activation with photovoltaic system that produces
electricity;
• Possible connection to the System Manager (optional) to manage
systems with more than 3 zones.
Supplied with sample points for combustion analysis, lower protection
guard, connection group, cock with lter on system ow, cock on the
system ow, gas interception cock and cold water cock.
Category II appliance
2H3B/P
functions with a natural gas, L.P.G. and
propane air.
It is available in the instant models:
• MAGIS COMBO 4 V2 code 3.030609
• MAGIS COMBO 4 V2 LPG code 3.030609LPG
• MAGIS COMBO 6 V2 code 3.030611
• MAGIS COMBO 6 V2 LPG code 3.030611LPG
• MAGIS COMBO 9 V2 code 3.030613
• MAGIS COMBO 9 V2 LPG code 3.030613LPG
Or it is available in the PLUS models:
• MAGIS COMBO 4 PLUS V2 code 3.030615
• MAGIS COMBO 4 PLUS V2 LPG code 3.030615LPG
• MAGIS COMBO 6 PLUS V2 code 3.030617
• MAGIS COMBO 6 PLUS V2 LPG code 3.030617LPG
• MAGIS COMBO 9 PLUS V2 code 3.030619
• MAGIS COMBO 9 PLUS V2 LPG code 3.030619LPG
• Installation template code 3.016848
"Split" inverter reversible air/water hybrid heat pumps, composed of
an Outdoor condensing unit and a Wall-hung indoor unit; a single
"pack" code identies the complete system consisting of the following
main components:
- Outdoor condensing unit (AUDAX PRO V2) which mainly includes
rotary compressor, inverter electronics, throttle valve, 4-way valve for
cycle inversion, nned exchange coil with outdoor air (with single
fan). e cooling circuit is already preloaded in the condensing unit
(refrigerant R32); it is equipped with shut-o valves for the R32
circuit;
- Wall-hung indoor unit, which includes:
• e hydraulic circuit components for connection to the system, as
well as the relevant management and communication electronics with
the condensing unit; in particular, it is composed of 72-plate R32 /
water exchanger, 10-litre system expansion vessel, ow-meter, 24 Vdc
power supply, management electronics;
• Condensing unit with 24 kW nominal useful power (20,640 kcal/h) in
central heating (27.3 kW in DHW) with total premixing combustion
system with steel multigas cylindrical burner, complete with ignition
electrode and ionisation control electrode and double shutter pneu-
matic gas valve, gas/water primary exchanger with composite casing
and stainless steel internal coil; stainless steel combustion chamber
internally insulated with ceramic panels, fan for ue gas evacuation
at electronically variable speed, circuit for the disposal of condensate
including siphon and exible drain hose;
• 14-plate stainless steel secondary water/water exchanger for the pro-
duction of domestic hot water, D.H.W. ow switch for detection of
withdrawal of D.H.W. (MAGIS COMBO V2 instant version);
• Hydraulic unit consisting of 3-way electric valve, low consumption 7
m.c.a. circulation pump (associated with the condensation generator
operation), low consumption 7 m c.a. circulation pump (associated
with cooling circuit operation), absolute pressure switch for the pri-
mary circuit, 3-bar primary circuit safety valve, system drain tting
and cock for system lling, in the MAGIS COMBO PLUS V2 there
is an additional 3-way electric valve to manage the D.H.W. central
heating with the heat pump circuit;
• Control panel composed of central heating system pressure gauge,
multifunction display and 7-digit keyboard for setting and adjusting
the generator operating parameters: central heating/cooling ow
temperature adjustment buttons, DHW temperature adjustment
buttons, summer / winter mode button, reset button, menu button;
• Self-diagnosis system with digital display of the functioning status
and error codes;
• Ignition delay device in C.H. mode, anti-freeze protection system (to
-5°C), pump anti-block device function, three-way valve anti-block
device function, chimney sweep function, automatic vent function,
screed heater function;
• IPX4D Electrical insulation rating;
• Possibility of coupling to the system for ducting of existing ues Ø
50 mm, Ø 60 mm and Ø 80 mm (for condensation units).
• Selection of C.H. temperature range via the programming menu;
• Hydraulically the indoor unit is set-up for connection to 1 heating/
cooling zone and for connection to the DHW storage tank (PLUS
version) or to the D.H.W. circuit (instant); there are also the R32
connections for the condensing unit;
• Compared with block heat pumps, the water circuit is fully protected
against freezing because it can be installed inside the home (important
in cold zones);
1 MAGIS COMBO 4 6 9 V2 SINGLEPHASE, INSTANT AND PLUS FEATURES
