Immergas MAGIS COMBO V2 - Magis Combo V2; Magis Combo Plus V2 (Heat Pump) Technical Data

MAGIS COMBO V2
35
4 V2 6 V2 9 V2
Central heating circuit
Power in CH mode with water set at 35 °C
(1)
kW 4.40 6.00 9.00
Power in CH mode with water set at 45 °C
(2)
kW 4.20 5.40 8.60
Power in CH mode with water set at 55 °C
(3)
kW 3.90 4.80 8.00
CH mode COP with water set at 35 °C
(1)
5.20 4.92 4.81
CH mode COP with water set at 45 °C
(2)
3.85 3.58 3.69
CH mode COP with water set at 55 °C
(3)
2.95 2.65 2.93
Flow temperature range °C 20 ÷ 65 20 ÷ 65 20 ÷ 65
Outdoor temp. limits for Heating mode operation °C - 25 ÷ 35 - 25 ÷ 35 - 25 ÷ 35
Cooling circuit
Power in cooling mode with water set at 18 °C
(1)
kW 5.00 6.50 8.70
Power in cooling mode with water set at 7 °C
(2)
kW 3.60 4.70 6.50
Cooling mode EER with water set at 18 °C
(1)
4.59 4.42 4.12
Cooling mode EER with water set at 7 °C
(2)
3.24 3.26 3.33
Flow temperature range °C 5 ÷ 25 5 ÷ 25 5 ÷ 25
Outdoor temp. limits for Cooling mode operation °C 10 ÷ 46 10 ÷ 46 10 ÷ 46
Maximum power absorbed
(condensing unit + Indoor unit) W 2100 2900 4300
Max. head available to the system
(with 1000 l/h flow rate) kPa (m c.a.) 48.78 (5.0) 48.78 (5.0) 48.78 (5.0)
Cooling circuit circulator power absorption W 75 75 75
General data
C.H. sound power level dB(A) 58 60 64
Hydronic module electric degree of protection IP X4D X4D X4D
Electric power supply V - Hz 230-50 230-50 230-50
Permitted voltage range V 198-264 198-264 198-264
Maximum absorbed current in normal operation A 16 16 22
Fuse required A 20 20 32
Refrigerant fluid load (R32) g 1200 1200 1400
Condensing unit weight (net) kg 49.5 (46.5) 49.5 (46.5) 81.5 (73.0)
22 MAGIS COMBO V2 / MAGIS COMBO PLUS V2 HEAT PUMP TECHNICAL DATA
THE REPORTED DATA REFERS TO THE FOLLOWING CONDITIONS (in compliance with EN 14511)
:
ROOM CENTRAL HEATING PHASE (°C) COOLING PHASE (°C)
Water TEMP. (F/R)
(1)
- AIR (db/wb) 35/30 - 7/6 18/23 - 35 (bs)
Water TEMP. (F/R)
(2)
- AIR (db/wb) 45/40 - 7/6 7/12 - 35 (bs)
Water TEMP. (F/R)
(3)
- AIR (db/wb) 55/47 - 7/6
