MAGIS COMBO V2
25
Terminal 87
0 V Close Winter
230 V Open Summer with cooling
KEY:
1 - Open / Close
2 - Close
3 - Open
4 - Valve with spring return
5 - 2-point valve
6 - Auxiliaries
M10-1 - Zone 1 circulator pump
M10-2 - Zone 2 circulator pump
M10-3 - Zone 3 circulator pump
M31-2 - Zone 2 mixing valve
M52 - Hot/cold 3-way
S39 - Solar inlet
S41 - AUDAX PRO V2 disabling
rough the congurable relay interface kit (optional) it is also
possible to manage a 3rd zone (mixed) on the system, the pump
of zone 3 will need to be connected as shown in the diagram
(M10-3). e zone 3 dehumidier, if any, will be managed by
means of the congurable relay interface kit, which the zone 3
mixer will also be connected to. In this way 1 direct zone + 2
mixed zones can be controlled.
N.B.: To control the dehumidiers, insert the relay board kit
(optional) inside the MAGIS COMBO V2 wall-hung indoor
unit, for the respective dehumidiers of the two zones. e relay
board kit has only one contact for each zone and, therefore, al-
lows the dehumidier to work either in neutral air or in cooled
air. For further information see the chapter on dehumidiers.
