INSTALLERUSERMAINTENANCE TECHNICIANTECHNICAL DATA
1
2
3
3
4
5
6
7
6
8
9
A
10
11
12
30
e adapter kit includes (Fig. 30):
N°1 Door adaptor Ø 100 or Ø 125 (1)
N°1 Door gasket made of neoprene (2)
N°4 Screws 4.2 x 9 AF (3)
N°1 Hex headed screw M6 x 20 (4)
N°1 Flat nylon washer M6 (5)
N°2 Door hole closure metal-sheet plate plug (6)
N°1 Plug gasket made of neoprene (7)
N°1 Toothed washer M6 (8)
N°1 Nut M6 (9)
N°1 (kit Ø 80/125) Concentric gasket Ø 60/100 (10)
N°1 (kit Ø 80/125) Flanged adapter Ø 80/125 (11)
N°4 (kit Ø 80/125) Hex headed screws M4 x 16 slotted screwdriver (12)
N°1 (kit Ø 80/125) Bag of lubricating talc
Supplied separately (Fig. 30):
N°1 Ducting kit door (A)
Technical data
e dimensions of the shas must ensure a minimum gap between the outer wall of the smoke duct and the inner wall of the sha: 30 mm
for circular section shas and 20 mm in the event of a square section sha (Fig. 29).
Maximum 2 changes of direction are allowed on the vertical section of the ue system with a maximum clearance angle of 30° with re-
spect to the vertical.
e maximum vertical extension using a Ø 60 ducting system is 13 m, the maximum extension includes 1 bend Ø 60/100 at 90°, 1 m of
horizontal pipe Ø 60/100, 1 x 90° Ø 60 ducted bend and the roof terminal for ducting.
Free
e maximum vertical extension using a Ø 80 rigid ducting system is 28 m, the maximum extension includes 1 adapter from Ø 60/100 to
Ø 80/125, 1 bend Ø 80/125 of 87°, 1 m of pipe Ø 80/125 in horizontal, 1 x 90° ducted bend Ø 80 and the roof terminal for ducting.
To determine the C
93
ue system in congurations other than that described (Fig. 31) one must consider the following head losses:
- 1 m of concentric pipe Ø 80/125 = 1.8 m of rigid ducted pipe Ø 80 and 0.7 m of exible ducted pipe Ø 80;
- 1 curve Ø 80 of 87° = 2.1 m of rigid ducted pipe Ø 80 and 0.9 m of exible ducted pipe Ø 80.
Consequently one must subtract the equivalent length of the part added to the 28 m available.
C
93
X
31
