21
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
1.10 REMOTE CONTROLS AND ROOM CHRONOTHERMOSTATS OPTIONAL
e appliance is set up for room chrono-thermostats or remote controls, available as optional kits (Fig. 9).
All Immergas chrono-thermostats are connected with 2 wires only.
Carefully read the user and assembly instructions contained in the accessory kit.
Disconnect power to the unit before making any electrical connections.
9
On/O Immergas digital chrono-thermostat.
e chrono-thermostat allows:
- set two room temperature value: one for day (comfort temperature) and one for night (reduced temperature);
- set a weekly programme with four daily switch on and switch o times;
- selecting the required function mode from the various possible alternatives:
• manual mode (with adjustable temperature);
• automatic mode (with set programme);
• forced automatic operation (momentarily changing the temperature of the automatic program).
e chrono-thermostat is powered by two 1.5V LR 6 type alkaline batteries.
“Comando Amico Remoto” (Remote Control Device)
V2
(CAR
V2
) with climate chrono-thermostat function.
In addition to the functions described in the previous point, the CAR
V2
panel enables the user to control all the important information
regarding operation of the appliance and the heating system with the opportunity to easily intervene on the previously set parameters,
without having to go to where the appliance is installed.
e panel is equipped with self-diagnosis to show any appliance operating anomalies on the display.
e climate chrono-thermostat incorporated into the remote panel enables the system ow temperature to be adjusted to the actual
needs of the room being heated, in order to obtain the desired room temperature with extreme precision and therefore with evident sav-
ing in running costs.
e CAR
V2
is fed directly by the appliance by means of the same 2 wires used for the transmission of data between the appliance and de-
vice.
