1.16 CONCENTRIC HORIZONTAL KIT INSTALLATION
Type C conguration, sealed chamber and fan assisted
e position of the terminal (in terms of distances from openings, overlooking buildings, oor, etc.) must be in compliance with the reg-
ulations in force.
is terminal is connected directly to the outside of the building for air intake and ue gas exhaust.
e horizontal kit can be installed with the rear, right side, le side or front outlet.
For installation with frontal outlet, one must use the xing plate and a concentric bend coupling in order to ensure sucient space to
carry out the tests required by law upon commissioning.
External grid
Both the Ø 60/100 and Ø 80/125 intake/exhaust terminal, if properly installed, is pleasant to look at on the outside of the building.
Make sure that the external silicone wall sealing plate is properly inserted in the wall.
For correct functioning of the system the terminal with grid must be installed correctly ensuring that, the "high" indication
present on the terminal is respected on installation.
Mounting the horizontal intake-exhaust kit Ø 60/100 (Fig. 18)
1. Install the curve with ange (2) on the central hole of the appliance, positioning gasket (1) with the circular projections downwards in
contact with the appliance ange, and tighten using the screws contained in the kit.
2. Fit the Ø 60/100 (3) concentric terminal pipe with the male side (smooth) to the female side of the bend (2) up to the end stop, making
sure that the internal and external wall sealing plates have been tted; this will ensure sealing and joining of the elements making up
the kit.
C
13
5
4
3
1
2
18
e kit includes (Fig. 18):
N°1 Ga ske t (1)
N°1 Concentric bend Ø 60/100 (2)
N°1 Int./exhaust concentric terminal
Ø 60/100 (3)
N°1 Internal wall sealing plate (4)
N°1 External wall sealing plate (5)
Extensions for Ø 60/100 horizontal kit. Kit assembly (Fig. 19)
e kit with this conguration can be extended up to a max. horizontal length of 12.9 m including the terminal with grid and excluding
the concentric bend leaving the boiler. is conguration corresponds to a resistance factor of 100. In this case specic extensions must
be requested.
is conguration corresponds to a resistance factor of 100.
In this case the special extensions must be requested.
Immergas also provides a Ø 60/100 simplied terminal, which in combination with its extension kits allows you to reach a maximum
extension of 11.9 metres.
