INSTALLERUSERMAINTENANCE TECHNICIANTECHNICAL DATA
Mounting the horizontal intake-exhaust kit Ø 80/125 (Fig. 20)
To install the kit Ø 80/125 one must use the anged adapter kit in order to install the ue system Ø 80/125.
1. Install the anged adaptor (2) on the central hole of the appliance, positioning gasket (1) with the circular projections downwards in
contact with the appliance ange, and tighten using the screws contained in the kit.
2. Engage the bend (3) with the male side (smooth) to the end stop on the adapter (1).
3. Fit the Ø 80/125 (5) concentric terminal pipe with the male side (smooth) to the female side of the bend (4) (with lip seals) up to the end
stop, making sure that the internal (6) and external wall sealing plates (7) have been tted; this will ensure sealing and joining of the
elements making up the kit.
C
13
1
2
3
4
5
6
20
e adapter kit includes (Fig. 20):
N°1 Ga ske t (1)
N°1 Adapter Ø 80/125 (2)
e Kit Ø 80/125 includes (Fig. 20):
N°1 Concentric bend Ø 80/125 at 87° (3)
N°1 Int./exhaust concentric terminal
Ø 80/125 (4)
N°1 Internal wall sealing plate (5)
N°1 External wall sealing plate (6)
e remaining kit components must not be used
Extensions for Ø 80/125 horizontal kit. Kit assembly (Fig. 21)
e kit with this conguration can be extended up to a max. length of 32 m, including the terminal with grid and excluding the concen-
tric bend leaving the appliance.
If additional components are assembled, the length equivalent to the maximum allowed must be subtracted.
In this case the special extensions must be requested.
C
13
21
1.17 CONCENTRIC VERTICAL KIT INSTALLATION
Type C conguration, sealed chamber and fan assisted
Concentric vertical intake and exhaust kit.
is vertical terminal is connected directly to the outside of the building for air intake and ue gas exhaust.
e vertical kit with aluminium tile enables installation on terraces and roofs with a maximum slope of 45% (approx. 25°) and
the height between the terminal cap and half-shell (374 mm for Ø 60/100 and 260 mm for Ø 80/125) must always be observed.
