1.15 INTERNAL INSTALLATION USING A RECESSED FRAME WITH DIRECT AIR INTAKE
Conguration type B, open chamber and fan assisted
Using a kit separator one can achieve direct air intake (Fig. 16) and ue gas exhaust in a single chimney or directly outside.
In this conguration the boiler is classied as type B
23
.
With this conguration:
- air intake takes place directly from the environment in which the appliance is installed (the recessed frame is ventilated), and only
functions in permanently ventilated rooms;
- the ue gas exhaust must be connected to its own individual chimney and channelled directly into the external atmosphere.
e technical regulations in force must be respected.
16
Separator kit installation (Fig. 17).
1. Install the discharge ange on the central hole of the boiler, positioning the relative gasket with the circular projections downwards in
contact with the boiler ange, and tighten using the hex screws with at tip contained in the kit.
2. Remove the at ange present in the lateral hole with respect to the central one (according to needs) and replace it with the intake
ange, positioning its gasket already present in the boiler and tighten using the supplied self-threading screws.
3. Fit the bends with male side (smooth) in the female side of the anges (the intake bend should face the rear side of the boiler).
4. Fit the exhaust pipe with the male side (smooth) to the female side of the bend up to the end stop, making sure that the internal wall
sealing plate has been tted and connecting the required ue according to personal requirements.
Max. length of exhaust duct.
e ue pipe (both vertical or horizontal) can be extended to a max. length of 36 linear metres.
