6-11 SECTION 6. GENERAL REFERENCE99903514:TELESCOPIC CRANE: 20030115
When using the torque data in the charts above, the following rules should be observed.
1. Bolt manufacturer’s particular specifications should be consulted when provided.
2. Flat washers of equal strength must be used.
3. All torque measurements are given in foot-pounds. To convert to inch-pounds, multiply by 12.
4. Torque values specified are for bolts with residual oils or no special lubricants applied.
If special lubricants of high stress ability, such as Never-Seez compound graphite and oil, molybdenum
disulphite, collodial copper or white lead are applied, multiply the torque values in the charts by the
factor .90. The use of Loctite does not affect the torque values listed above.
5. Consult the parts manual for torque values on socket head capscrews.
WARNING
Anytime a gear-bearing bolt is removed, it must be replaced with a new bolt of the identical grade and size. Once a bolt
has been torqued to 75% of its proof load and then removed, the torque coefficient may no longer be the same as when
the bolt was new thus giving indeterminate clamp loads after torquing. Failure to replace gear-bearing bolts may result in
bolt failure due to metal fatigue causing serious injury or DEATH.
5/16-24 0.3125 19 14 27 20
3/8-24 0.3750 35 26 49 35
7/16-20 0.4375 55 41 78 58
1/2-20 0.5000 90 64 120 90
9/16-18 0.5625 120 90 170 130
5/8-18 0.6250 170 130 240 180
3/4-16 0.7500 300 225 420 315
7/8-11 0.8750 445 325 670 500
1-12 1.0000 645 485 995 745
1 1/8-12 1.1250 890 670 1445 1085
1 1/4-12 1.2500 1240 930 2010 1510
1 3/8-12 1.3750 1675 1255 2710 2035
1 1/2-12 1.5000 2195 1645 3560 2670
SIZE BOLT DIA PLAIN PLATED PLAIN PLATED
(DIA-TPI) (INCHES) (FT-LBS) (FT-LBS) (FT-LBS) (FT-LBS)
SAE J429
GRADE 5
SAE J429
GRADE 8
TIGHTENING TORQUE
5/16-18 0.3125 17 13 25 18
3/8-16 0.3750 31 23 44 33
7/16-14 0.4375 49 37 70 52
1/2-13 0.5000 75 57 105 80
9/16-12 0.5625 110 82 155 115
5/8-11 0.6250 150 115 220 160
3/4-10 0.7500 265 200 375 280
7/8-9 0.8750 395 295 605 455
1-8 1.0000 590 445 910 680
1 1/8-7 1.1250 795 595 1290 965
1 1/4-7 1.2500 1120 840 1815 1360
1 3/8-6 1.3750 1470 1100 2380 1780
1 1/2-6 1.5000 1950 1460 3160 2370
SIZE BOLT DIA PLAIN PLATED PLAIN PLATED
(DIA-TPI) (INCHES) (FT-LBS) (FT-LBS) (FT-LBS) (FT-LBS)
SAE J429
GRADE 5
SAE J429
GRADE 8
TIGHTENING TORQUE
FINE THREAD BOLTS COARSE THREAD BOLTS
TORQUE DATA CHART - DOMESTIC
