Industrial Indexing Systems MSC-250 User Manual

INDUSTRIAL INDEXING SYSTEMS, INC. IB-11B012
MOTION CONTROL SYSTEM, MSC-250 USER'S GUIDE
MARCH 2003 DESCRIPTION 1 - 25
AC INPUT MODULE (IAC15)
Input Voltage Range 12 to 140 VAC
Input Current at Max. Line 11 ma
Input allowed for No Output 3 ma (45 V)
Isolation Voltage (Input-to-output) 4000 V
rms
Turn-on Time 20 ms max.
Turn-off Time 20 ms max.
NOTE
Do not use the IAC15 module for applications intended to be used in the
European Community.
DC OUTPUT MODULE (ODC15)
Operating Voltage Range 5 to 60 VDC
Current Rating (at 70°F) 2 amps
One Second Surge 5 amps
Output Voltage Drop 1.6 max.
Off-state Leakage at Max. Voltage 1 ma
Isolation Voltage (Input-to-output) 4000 V
rms
Turn-on Time 100 microseconds
Turn-off Time 750 microseconds
AC OUTPUT MODULE (OAC15)
Operating Voltage Range 12 to 140 VAC
Current Rating (at 70°F) 2 amps
One Cycle Surge 80 amps peak
Minimum Load Current 20 ma
Output Voltage Drop 1.6 max. peak
Off-state Leakage
at Nominal Voltage (60 Hz) 5 ma
rms
Isolation Voltage (Input-to-output) 4000 V
rms
Operating Frequency 25 to 65 Hz
Turn-on Time 100 microseconds
Turn-off Time 750 microseconds
NOTE
Do not use the OAC15 module for applications intended to be used in the
European Community.
