INDUSTRIAL INDEXING SYSTEMS, INC. IB-11B012
MOTION CONTROL SYSTEM, MSC-250 USER'S GUIDE
AUGUST 1998 MAINTENANCE 4 - 1
SECTION 4 − MAINTENANCE
WARNING
DISCONNECT ALL POWER AND FOLLOW PROPER LOCK-OUT
PROCEDURES BEFORE ATTEMPTING REPAIRS OR ADJUSTMENTS
TO THIS EQUIPMENT. ALLOW ONLY PROPERLY TRAINED
PERSONNEL TO SERVICE THIS EQUIPMENT.
4.1 COMPONENT REPLACEMENT
Components which may require replacement on the MSC-250 include the battery and the
firmware. The battery which protects the non-volatile memory must be replaced whenever
the battery voltage drops below 2.6 V. This battery is located at the upper right of the
MSC-250 circuit board (refer to Figure 4.1).
Industrial Indexing Systems, Inc. is continuously working to improve its products.
Occasionally, these improvements are significant enough to warrant upgrades to existing
controllers. These upgrades are supplied in the form of new firmware chips which must be
replaced by the customer.
4.1.1 BATTERY REPLACEMENT
CAUTION
WHEN THE BATTERY IS REMOVED FROM THE CONTROLLER WITH
ALL POWER TURNED OFF, ANY MACROPROGRAM STORED IN
MEMORY WILL BE LOST. MAKE SURE THE MACROPROGRAM HAS
BEEN BACKED UP ON A PROM OR CAN BE RESTORED FROM A
PERSONAL COMPUTER BEFORE REMOVING THE BATTERY FROM
THE CONTROLLER.
1. Turn off all power to the controller and open the cover.
2. Locate the battery on the circuit board and note the orientation of the positive and
negative contacts of the battery.
3. Gently lift the metal spring clip which holds the battery in place and remove the old
battery from the circuit board. DO NOT FORCE THE SPRING CLIP UP TOO HIGH
OR IT MAY BE DAMAGED.
