Inficon CU1000 User Manual

4 | Description INFICON
10 / 46 CU1000-Operating-Instructions-jina54en1-09-(2404)
4.2 Function
You can use the control unit to configure the mass spectrometer module LDS3000. It
also lets you output the data stored in the MSB box.
4.3 Technical data
Mechanical data
560-320
Dimensions (lxwxh) 106,2 mm x 128,4 mm x 49,2 mm
Electrical data
560-320
Memory capacity for measured data 16 MB
Ambient conditions
560-320
Max. altitude above sea level 2000 m
Max. relative humidity above 40 °C 50%
Max. relative humidity from 31 °C to 40 °C 80% to 50% (linear abfallend)
Max. relative humidity to 40 °C 80%
Permissible ambient temperature (during
operation)
10°C - 45°C
Storage temperature -20°C - 60°C
Pollution degree 2

Inficon CU1000 Specifications

General

Brand	Inficon
Model	CU1000
Category	Controller
Language	English
