Load parameters
The saved/backed-up parameters of control unit CU1000 and of the mass
spectrometer module can be loaded from a USB stick.
Control unit Function > Data > Parameters > Load
Save parameters
The parameters of control unit CU1000 and of the mass spectrometer module can be
saved to a USB flash drive.
Control unit Function > Data > Parameters > Save
Display error
information
The type of error information can be set differently for each operator type. The
Integrator always receives the complete information.
Number: Message number
text: Brief description
Info: Expanded message information
• Only numbers
• Number and text
• Number, text and info
Control unit Function > Data > Parameter > Error info
Viewer (Operator, Supervisor)
Parameter list display
and change
Parameters can be displayed as an alphabetical list with names and current value s.
Each list entry is a button which, when pressed, will open the parameter's set-up
dialog box.
Control unit List > Parameters list or:
Functions > Data > Parameters > List
Display list of
parameter change
authorizations
Parameters can be displayed as an alphabetical list with names and current change
authorizations. Each list entry is a button which, when pressed, will change access
control. Changes are possible in accordance with the hierarchy of the operator.
Control unit Functions > Data > Parameters >
Parameter Access
6.3.2.1 Logging out the operator
The operator activates access level "Viewer" to log out. "Access Ctrl > Viewer"
6.3.3 Reset settings
Mass spectrometer
module
The settings of the mass spectrometer module can be reset to factory settings.
Control unit Functions > Data > Parameters > Reset >
MSB settings
Access controls
The authorization for changing parameters can be reset to factory setting.
Control unit Functions > Data > Parameters > Reset >
Param. Access control
