Inficon CU1000

INFICON Operation CU1000 | 6
CU1000-Operating-Instructions-jina54en1-09-(2404) 31 / 46
Fig.8: Top left: Display of Molar Mass (102) and Equivalence Factor (127)
6.3.7 Updating the software
Software updates from INFICON are installed with the aid of a USB flash drive. The
update function of the device can be found under "Functions > Data > Update".
An update is possible,
• if one or several updates are available on the USB flash drive, but only one update
per type at most (control unit, MSB box, I/O module),
• if these parts are also connected free of disturbances and have an update
function.
The corresponding buttons in the update menu such as "Control Unit", "MSB Box",
and "I/O Module" are active and can be activated individually.
NOTICE
Aborted connection
Loss of data due to disconnection
► Do not switch off the device and do not remove the USB flash drive while the
software is being updated!
► Switch the device off and back on after a software update has taken place.
