21
English
Installation
Adjusting the Projector’s Zoom / Focus
You may turn the zoom ring to zoom in or out. To focus the im-
age, rotate the focus ring until the image is clear.

Standard throw series: The projector will focus at distances
from 3.94 to 24.61 feet (1.2 to 7.5 meters).
Adjusting Projection Image Size

Projection Image Size from 37.0” to 301.0” (0.94 to 7.65
meters).
Width
Height
Diagonal
Top View
Side View
Projection Distance (D)
Projection Distance (D)
Screen
Screen
Screen (W)
Screen (H)
Offset (Hd)
Focus Ring
Zoom Lever
