LP340 / LP350 Service Guide 107
Optical Engine Exploded View
All the parts in the illustration below are included in a new optical engine. They are also available
separately. The lamp housing also includes the 80mm fan, the lamp blower and the safety switch cable.
Lamp blower
526-0056-xx
Optical engine
LP340: 530-0111-xx
80mm fan
526-0057-xx
Safety switch cable
(includes thermal switch and interlock switch)
526-0057-xx
Lamp housing
LP340: 505-0631-xx
