LP340/340B/350 Service Manual 67
Fasteners
The fastener kit (802-0023-xx) contains a selection of each of the fasteners listed below. Torque settings
for each fastener are listed in the parts replacement procedures.
Size Used in
M3x8 TORX SEM
Keypad to top case (2); speaker/fan assembly (1); power supply to
chassis (9); optical engine to top case (2); controller ECA to chassis
(7)
M3x10 Phillips SEM
DMD stiffener and spring shields to controller ECA (4)
M3x8 Black TORX
Bottom case to chassis (5); front bezel to chassis (1); rear bezel to
chassis (1)
M2.6x8 PHP
I/O shield to controller ECA at CableWizard connector (2)
M3x8 TORX SQ Cone, SEM
Lamp housing to optical engine (2)
6-32x3/8 PHP Zinc
DMD heat sink to heat spreader (2)
Jack screws
I/O shield to controller ECA at M1 connector (2)
M3x20 TORX
60mm lamp fan to lamp housing (2); lamp blower to lamp housing (2)
M3x12 TORX
lamp blower bracket to lamp housing (1)
