LP340 / LP350 Service Guide 108
FRUs by alphabetic listing
Below is an alphabetically arranged list of FRUs used in the LP340/350.
Part Name Projector Part Number Notes
Blower, lamp All 526-0056-xx Also included with new optical engine and new lamp
housing.
Bottom case LP340,
LP350
505-0635-xx Includes the elevator assembly. Requires a certification
label, and product label.
Bottom case LP340B 505-0928-xx Includes the elevator assembly. Requires a certification
label, and product label.
Chassis All 330-0602-xx
Controller ECA LP350 510-1485-xx
or
510-1524-xx
The 1485 and 1524 controllers are identical.
When installing a new controller ECA, you must check and
adjust the DMD bias setting. See Updating the DMD bias
setting for instructions.
Controller ECA LP340 510-1508-xx The 1508 and 1523 controllers are identical.
When installing a new controller ECA, you must check and
adjust the DMD bias setting. See Updating the DMD bias
setting for instructions.
Controller ECA LP340B 510-1573-xx When installing a new controller ECA, you must check and
adjust the DMD bias setting. See Updating the DMD bias
setting for instructions.
DMD cap All 340-0601-xx Plastic cover with Velcro strap used to secure DMD to
engine housing when removing the engine.
DMD mounting kit All 505-0778-xx Includes DMD heat sink, DMD stiffener, 2 DMD EMI
shields, DMD stiffener insulator, and fasteners.
DMD elastomer kit All 505-0779-xx Includes 2 elastomers, DMD retainers, and DMD carriers.
Fan, 80 mm lamp All 526-0058-xx Fastens to the lamp housing. Also included with new
optical engine and with new lamp housing.
Fan, 60 mm All 526-0057-xx Fastens to the speaker/fan bracket.
Elevator kit All 505-0076-xx Includes elevator shaft, actuator and spring. Included in a
new bottom case.
Fastener kit All 802-0023-xx Includes 10 of each fastener used to fasten FRUs.
Focus ring All 505-0640-xx
Front bezel All 505-0636-xx Includes the IR lens.
I/O EMI shield LP340,
LP350
330-0604-xx
