LP340 / LP350 Service Guide 109
I/O EMI shield LP340B 330-0461-xx
Keypad All 526-0050-xx Includes keypad ECA, buttons and keypad cable.
Label, certification LP340 020-0972-xx Required for new bottom case.
Label, certification LP340B 020-1114-xx Required for new bottom case.
Label, certification LP350 020-0973-xx Required for new bottom case.
Label, model LP340 020-0975-xx Required for new bottom case.
Label, model LP340B 020-1115-xx Required for new bottom case.
Label, model LP350 020-0976-xx Required for new bottom case.
Lamp door All 505-0638-xx
Lamp housing All 505-0632-xx Includes 60 mm lamp fan, blower and ducting, and safety
switches.
Lamp module All SP-LAMP-
LP3F
Lens cap All 340-0686-xx
Leveling foot kit All 505-0777-xx Includes leveling shaft, leveling foot and screw.
Nameplate,
InFocus, rear
All 505-0668-xx Fits onto rear bezel.
Nameplate,
InFocus, top
All 020-0846-xx Required for new top case.
Optical engine LP340,
LP340B
530-0111-xx Includes all components in the light path except the lamp.
Includes DMD cover to protect DMD.
Optical engine LP350 530-0110-xx Includes all components in the light path except the lamp.
Includes DMD cover to protect DMD.
Power supply
insulator
All 120-0147-xx UL-approved paper insulator fits between power supply
and chassis.
Power supply All 510-1486-xx
Rear bezel All 505-0637-xx
Rubber foot All 328-0029-xx One foot each.
Speaker All 526-0059-xx Also included in the speaker/fan bracket assembly.
Speaker/fan
bracket
All 505-0643-xx Includes speaker, fan and bracket.
Safety switches
w/cable
All 526-0049-xx Includes thermal switch, interlock switch, and cable.
Top case LP340 505-0634-11 InFocus name plate required for new top case.
Top case LP340B 505-0926-xx InFocus name plate required for new top case.
Top case LP350 505-0634-01 InFocus name plate required for new top case.
