XtrapulsCD1-a
Chapter 2 - Specifications
digital oscilloscope (current, speed or position) or "Phasing
OK" output (for incremental encoder without HES)
Error display
LED on front panel and diagnostic by serial link
Parameter setting
Serial link RS-232 as standard (RS-422 optional)
Automatic functions
Drive adjustment to the motor (AUTOPHASING)
Automatic regulator adjustment (AUTOTUNING)
Offset compensation on analog input
Compliance with the standards: CE certification
"360°" shield; equipotentiality according to the
wiring rules.
XtrapulsCD1-a-400/70 and 90 A with F-400-70/90
mains filter.
EMC standards:
- Immunity: EN 61000.4-2-3-4-5
- Conducted and radiated disturbances: EN 55011,Group 1,
C3 category
Electrical standards for industrial machines:
- EN 60204.1: - Insulator: 1500 VAC/1 min.
- Leakage current > 30 mA (EMI filters)
Compliance with the standards: UL listing
"360°" shield; equipotentiality according to the
wiring rules.
XtrapulsCD1-a series have been “
c
UL
us
” listed according to
UL508C and UL840 regarding the insulator.
This product was evaluated to:
- the Third Edition of UL508C, the UL Standard for Power
Conversion Equipment for the UL Listing (USL),
- the CSA Standard for Industrial Control Equipment, C22.2
N° 14-10 for the Canadian UL Listing (CNL).
Temperature
- storage - 20°C to + 70°C
- operation 5°C to +40°C
From 40°C on, the rated currents must be reduced of 3 % per
additional °C.
Max. temperature: 50°C
Altitude
1000 m
Moisture
< 50 % at 40°C and < 90 % at 20°C: (EN 60204.1 standard)
Condensation prohibited (storage and operation)
Cooling
Forced air (fan integrated in the CD1-a drive)
Check for free ventilation and no upper or lower obstruction of
the air admissions
Environment
Open chassis to be mounted in a housing protecting the drive
from conducting dust and condensation (pollution degree 2
environment)
Mounting position
Vertical
Mounting location
Closed cabinet without any conducting and/or corroding
agents and according to the room temperature requirements.
Condensation prohibited.
Weight
XtrapulsCD1-a-230/I: approx. 1.5 kg
XtrapulsCD1-a-400/1.8 to 7.2 A: approx. 2 kg
XtrapulsCD1-a-400/14: approx. 3 kg
XtrapulsCD1-a-400/30 and 45: approx. 5 kg
XtrapulsCD1-a-400/70 and 90: approx. 6 kg
