Infranor XtrapulsCD1-a Series User Manual

8
Chapter 2 – Specifications
XtrapulsCD1-a
Chapter 2 - Specifications
1 - TECHNICAL SPECIFICATIONS
1.1 – XTRAPULS CD1-a-230/I DRIVE
Mains operating power supply 230 VAC +10 % / -15 %, 1~ or 3~, 50 - 60 Hz
Isolated galvanic auxiliary supply voltage 24 VDC +/- 15 % - 320 mA
Motor phase-phase output voltage 200 Vrms
Integrated braking system External 100 Ohm / 100 W resistor (dp 100/100)
Minimum resistance: 50 Ohm (dp 50/200)
Minimum inductance between phases 1 mH
Drive output current ratings
Drive type
Max. output
current (Arms)
for 1 sec.
+/- 5 %
(230 VAC)
Rated
output
current
(Arms)
(230 VAC)
Power
losses
(W)
Rated input
current (Arms)
(230 VAC,
60 Hz)
Max. protection
fuses for line
circuit
RK5 listed
(Bussman /
Littelfuse)
Short-
circuit
power of
the mains
UL listed
CD1-a-230/2.25
2.25
1.1
25
1.1
6 A
5 kA
yes
CD1-a-230/4.5
4.5
2.25
30
2.25
6 A
5 kA
yes
CD1-a-230/7.5
7.5
3.75.
44
3.75
6 A
5 kA
yes
CD1-a-230/10.5
10.5
5.25
55
5.25
6 A
5 kA
yes
CD1-a-230/16.5
16.5
8.25
66
8.25
9 A
5 kA
yes
Maximum room temperature = 40° C.
1.2 – XTRAPULS CD1-a-400/I DRIVE
Mains operating power supply voltage
400 to 480 VAC + 10 %/- 15 % 3~, TN or TT system with
earthed neutral point, 50 - 60 Hz
(Phase/Ground voltage must be balanced)
Isolated auxiliary supply voltage
24 VDC +/- 15 % - 320 mA
Motor phase-phase output voltage
380 to 460 Vrms depending on the mains
Integrated braking system
XtrapulsCD1-a-400/1.8 to 7.2 A:
External 200 Ω/100 W resistor (dp 200/100)
Minimum resistor value: 150 /100 W
XtrapulsCD1-a-400/14:
External 50 Ω/200 W resistor (dp 50/200)
XtrapulsCD1-a-400/30 and 45:
External 33 Ω/280 W resistor (dp 33/280)
XtrapulsCD1-a-400/70 and 90:
External 16.5/560 W resistor (dp 16.5/560)
Minimum inductance between phases
2 mH
OPERATING POWER RESTRICTION IN SINGLE-PHASE VOLTAGE
Continuous RMS power ensuring a capacitor lifetime of 20 000 hours:
- 650 W for CD1-a-230/2.25 to 10.5
- 1000 W for CD1-a-230/16.5.
!
