Infranor XtrapulsGem Installation Guide

10
Chapter 1– General
XtrapulsPac Installation Guide
1.4.2 - Connector sets
1.4.2.1 - Ordering code of the connector sets
If the connector kit is separately ordered from the drive, please use the following reference:
FXX - Pac - rrr
Connector set type
FL:
With command connector set
FC:
With power + motor connector set
FCL:
With power + motor + command connector set
Rating suffix (not required for FL set)
230
Connector kit for 230 V drives
402
Connector kit for 400 V / 08 A and 20 A drives
404
420
Connector kit for 400 V / 45 A and 100 A drives
Connector kit for 400 V / 200 A drives
1.4.2.2 - Connector set description
FC-Pac
X8: 5 pin plug connector for the auxiliary 24 V
DC
supply and for the motor brake.
X9: power plug connector for mains and motor.
X10: mains power plug connector for Pac 400 V / 08 to 20 A
FL-Pac
X1: male 15 pin Sub D connector for the resolver, with the appropriate conducting cover.
X2: female 26 pin Sub D HD connector for the logic I/Os, with the appropriate conducting cover.
X3: male 26 pin Sub D HD connector for the encoder, with the appropriate conducting cover.
X5: female 9 pin Sub D connector for the RS232 / CAN link, with the appropriate conducting cover.
FCL-Pac
X1: male 15 pin Sub D connector for the resolver, with the appropriate conducting cover.
X2: female 26 pin Sub D HD connector for the logic I/Os, with the appropriate conducting cover.
X3: male 26 pin Sub D HD connector for the encoder, with the appropriate conducting cover.
X5: female 9 pin Sub D connector for the RS232 / CAN link, with the appropriate conducting cover.
X8: 5 pin plug connector for the auxiliary 24 V
DC
supply and for the motor brake.
X9: power plug connector for mains and motor.
X10: mains power plug connector for Pac 400 V / 08 A to 20 A
