- analog,
- stepper motor emulation,
- logic I/Os.
But the XtrapulsPac range also offers more sophisticated functions such as:
- DS402 including position capture,
- Master/slave and electronic gearing functions,
- Positioner with motion sequencing.
All versions are delivered in standard with the integrated safety function Safe Torque Off (STO) SIL 2.
With its very small dimensions, the XtrapulsPac is available in various designs:
- stand-alone or multi-axis version,
- standard forced air, push-through or cold plate cooling versions.
Series XtrapulsPac drives are fully configurable in order to fit various applications. Both drive versions of the
XtrapulsPac range are described below.
The XtrapulsPac version with CANopen® interface can be used in the following application types:
Axes controlled by CANopen® fieldbus according to the DS402 protocol,
Stand-alone operation as a motion sequencer with control by means of logic I/Os,
Traditional analog speed drive with +/- 10 V command and position output by A, B, Z encoder signal
emulation,
Stepper motor emulation with PULSE and DIR command signals.
The XtrapulsPac version with EtherCAT® interface can be used in the following application types:
Axes controlled by EtherCAT® fieldbus according to the DS402 protocol,
Stand-alone operation as a motion sequencer with control by means of logic I/Os.
The configuration and parameterization software tool Gem Drive Studio allows a quick configuration of the
XtrapulsPac drives according to the target application (template).
