Chapter 3 – Inputs-Outputs
XtrapulsPac Installation Guide
Chapter 2 – Specifications
2.1 - MAIN TECHNICAL DATA
2.1.1 - XtrapulsPac-230/I
Design
Stand-alone
Available cooling version
Forced air (standard)
Operating power supply voltage
(1)
110 to 230 V
AC
+/- 10 % single-phase
50 - 60 Hz
Grounded neutral system with balanced phase to
ground voltage
Undervoltage threshold
(1)
100 V
DC
Braking threshold
(1)
390 V
DC
Overvoltage threshold
(1)
430 V
DC
EMC filter on the mains power supply
Fully integrated in the drive
Motor phase-to-phase output voltage
95 % of mains voltage
Integrated braking resistor
100 R / 35 W
External braking resistor
(1)
Minimum external resistor: 50 Ω
Infranor ordering code: dp 50/200
Minimum phase-to-phase inductance
(1)
1 mH
Galvanic isolated auxiliary supply voltage
24 V
DC
+/- 15 % - 400 mA (without motor brake)
EMC filter on auxiliary supply
Integrated in the drive
(1)
These values correspond to the default configuration of the drive. For lower operating voltage, see Appendix
"Low operating voltage".
OUTPUT CURRENT RATINGS
TYPE
Max.
output
current
for 1 s
(Arms)
+/-5 %
(230 V
AC
)
Rated
output
current
(Arms)
(230 Vac)
Power
losses
at rated
current
(W)
Rated input
current
(Arms)
(230 Vac,
60 Hz)
Certified max.
protection line
circuit fuses
A60Q
Mains
short-
circuit
power
UL
listed
Pac-230/5
5
2.5
20
4.3
10 A
5 kA
yes
Pac-230/11
11
5.5
40
9.5
15 A
5 kA
yes
Pac-230/17
17
8.5
65
14.7
20 A
5 kA
yes
Maximum surrounding air temperature: 40°C.
Note:
OPERATING POWER RESTRICTION
Maximum continuous RMS power ensuring a capacitor lifetime of 20'000 hours:
- 650 W for ratings 230/05 and 230/11,
- 1000 W for rating 230/17.
