User’s manual
Shortcuts 19
4-3-2
Shortcuts on keypad integrated readers
Users must hold their digital keys in the vicinity of the integrated reader (the position of the
reader is indicated by the symbol, instead, on the Alien keypad it is positioned on the
lower right-hand corner of the frontplate).
The key and reader shortcuts will flash one-by-one at 3 second intervals on the keypad
display. When the required shortcut is indicated, remove the key to activate the corresponding
action.
The shortcuts appear on the display in the following order:
1. Description of the first reader shortcut for 3 seconds
2. Description of the second reader shortcut for 3 seconds
3. Description of the third reader shortcut for 3 seconds
4. Description of the fourth reader shortcut for 3 seconds
5. Description of the key shortcut for 3 seconds
6. The “Disarm” string, to disarm all the partitions
7. Then back to point 1. and run through the sequence until the user removes the key,
thus selecting the shortcut described in the moment key is removed.
If, during this phase, any of the partitions are armed, the LED sequence will start at point 6.
4-3-3
Remote-control shortcuts
To activate the installer-programmed shortcuts assigned to the 4 keys , ..., on the
remote-control device, simply push the button which corresponds to the desired command.
The successful outcome of the operation will be signaled by audible and visual feedback (refer
to Table 7-3: Feedback signals provided by wireless keys).
4-4
Shortcut on event
The shortcuts on events are control panel functions which are triggered (activated) by the
occurrence of an event.
The definition of these functions and their triggers can be achieved only through appropriate
programming of the Prime control panel by the installer and cannot be implemented by the
user.
User key
Arm/Disarm
Scenario 004
Partit. notReady
User key
Activate Output
Cancel
User key
Arm/Disarm
Scenario 003
Partitions ready
3 seconds 3 seconds
