User’s manual
Using the Prime system 23
These operations can be carried out through:
•LCD Keypad (paragraph 6-6-3 Voice memo and intercom functions)
Alien keypad (paragraph 6-7-4 Voice memo and intercom functions
5-5
Activations
The activation (and deactivation) of the various elements of the Prime system allows them to
operate normally in accordance with their programming (= activation) or disable their
functions completely (= deactivation).
The user can activate or deactivate the following elements:
Zone - deactivated (disabled) zones cannot generate alarms (bypassed).
Auto-arm operations - can be activated/deactivated separately on each single partition.
If this option is enabled on a partition, it will arm and disarm in accordance with the On/Off
settings of the respective timer.
Codes - deactivated (disabled) codes cannot access the system.
Activation/Deactivation can be achieved only on hierarchically inferior codes (refer to
paragraph 3-1 User Codes).
Keys - deactivated (disabled) keys cannot access the system.
Keypads - deactivated (disabled) keypads do not permit code entry (or access to the
menu), therefore, they cannot manage shortcuts. However, the LEDs and display will be
refreshed.
Readers - deactivated (disabled) readers cannot provide access to the system, therefore,
cannot accept keys or generate commands. However, the LEDs will indicate the current
status of the system.
Timers - activated timers (On) manage their associated elements (partitions, codes, keys)
in accordance with their settings. Deactivated timers cannot time-manage their associated
elements, therefore, they will function in accordance with Timer Off status.
Note
All the timers will be activated automatically when you exit the programming session. You must
deactivate timers which are not used for system control purposes.
Dialer - a deactivated (disabled) dialer cannot send voice or digital calls. However, if duly
programmed, it will be able to manage incoming calls.
PSTN/GSM Answerphone - if activated (enabled), the control panel will answer
incoming calls (on the PSTN landline and GSM network) with the prerecorded
Answerphone” message.
- If activated (enabled), the Installer PIN will be accepted by the system and the installer
will have access to the Installer menu. If deactivated (disabled), entry of the installer PIN
will generate an “Invalid Code” event and the installer will be denied access to the
respective menu.
Sync IP2RX - if activated (enabled), the control panel will send a specific string to the
IP2RX software in order to allow its identification.
Registration- this section allows the Prime panel to access INIM Electronics cloud service.
The activations of the elements can be carried out from:
•LCD Keypad (paragraph 6-6-4 Activations)
Alien keypad (paragraph 6-7-5 Activations
Web browser (paragraph 9-3-3 Viewing and activations)
AlienMobile Application
InimCloud
5-6
Outputs management
The user can activate/deactivate manually the outputs the user code in question is authorized
to work on.
It is possible to activate/deactivate low-power open-collector or relay outputs and view their
status by means of the respective icons.
It is possible to activate/deactivate high-power relay outputs and view their supplied voltage
and relative power factor (cosij).
It is possible to view the supplied voltage of dimmer outputs.
The activations of the outputs can be implemented via:
•LCD Keypad (paragraph 6-6-6 Outputs management)
Alien keypad (paragraph 6-7-7 Outputs management
Proximity readers (paragraph 7-3-3 Outputs management)
