3.5 Installation
The System is designed for installation in a clinic environment. To install the System,
perform the following tasks:
▪ Check the System and all its components for damage.
▪ Add water. Use the Maintenance Screen.
▪ Connect cradle to the device (Fig. 3.1).
▪ Connect Handpiece to the connector and place into the cradle.
▪ Connect the Footswitch.
▪ Connect the power cord to the System inlet.
▪ Plug the System Power Cord into an appropriate electrical outlet.
Figure 3-1: Cradle Connections to the Device
3.6 Filling Water
Optimas System and DiolazeXL, Vasculaze and Lumecca Handpieces are shipped
without water. Distilled water must be used and failure to do so will void the service
warranty. For detailed instructions refer to Section 10 – System Maintenance.
3.7 Moving the System
▪ Turn the System off.
▪ Disconnect the Power Cord.
▪ Disconnect the Handpieces.
▪ Disconnect the Footswitch.
