By authorized service personnel only:
▪ System and Hand pieces full test and calibration is required to be done. Please
make sure to contact your local service center to perform this process.
Failure to replace your filters can lead to serious malfunctions of the
laser/IPL Handpieces!
11.6 Filling Water for DiolazeXL, Vasculaze and Lumecca
Optimas System, as well as, DiolazeXL, Vasculaze and Lumecca Handpieces are
shipped without water. When filling water upon installation, distilled water must be
used and failure to do so will void the service warranty.
During water filling, air bubbles can form inside the hoses which may cause water
flow issues. This instruction will help prevent this from occurring.
1. Open the back cover and take out the bottle.
2. Unscrew the water bottle cap (Figure 11.1).
3. Slowly pour distilled water into the bottle while water filter and tube are inside
the bottle to prevent over pouring (Figure 11.2).
4. Fill the bottle up to the maximum level.
5. Close the bottle cap and insert the bottle at the back of the System
(Figure 11.3).
6. Connect any DiolazeXL, Vasculaze or Lumecca 515 or 580 Handpiece.
7. Turn the System ON.
8. Select “Utilities” on the Main Menu (Figure 11.4).
