Section 5: System Operation
This section of the manual explains how to start the device, operate it, and turn it off.
Prior to using or connecting the Handpiece, inspect the System and
Handpiece for possible mechanical damage.
5.1 Device Start-Up
1. Connect the handpiece to the handpiece connector socket on the System.
2. Turn on Main Power switch at the rear panel.
3. Press the On-Off button on the control panel to turn the device on. The System
loads the software and enters the Login Screen.
4. Enter unique password to get access to the device. If password is correct the
System enters Menu Screen.
5. The System loads the software and enters a self-test mode. If any problem is
detected during the test the error message will appear (See Troubleshooting
Section in this manual). If the test is passed correctly then the System
automatically enters the Menu Screen.
6. Select the application from the Menu Screen and System will enter the
Treatment Screen.
7. Verify on the screen that the Software version is properly displayed and the
connected Handpiece type is recognized correctly.
8. Apply the Handpiece to the treated area, ensuring a full contact.
9. Select the treatment parameters using Up and Down keys.
10. Press the Standby icon that will change to Ready.
11. To start treatment, press the Footswitch for RF applicators, press the Hand-
Trigger button for IPL applicators, and press the Footswitch followed by the
Hand-Trigger press for laser applicators.
The following information relates to the lasers only –DiolazeXL and Vasculaze.
4. When Cooling Down is completed, within 1 minute, the icon will change to
Ready.
5. If the laser is not activated within 3min, the System will go back to Standby
mode.
6. Apply handpiece to the treated area, ensuring a full contact with pressure.
