means that the indicator is on, and means that the indicator is off.
Hz: unit of frequency
Hz A V
RPM
%
A: unit of current
V: unit of voltage
RPM: unit of rotational speed
Hz A V
RPM
%
%: percentage
z Digital Display
The 5-digit LED display is able to display the set frequency, output frequency, monitoring
data and error codes.
4.1.2 Description of Keys on the Operation Panel
Table 4-1 Description of keys on the operation panel
Key Name Function
PRG Programming key Enter or exit Level I menu.
ENTER Confirm key
Enter the menu interfaces level by level, and confirm the
parameter setting.
Increment key Increase data or function code.
Decrement key Decrease data or function code.
Shift key
Select the displayed parameters in turn in the stop or running
state, and select the digit to be modified when modifying
parameters.
RUN Run key Start the AC drive in the operation panel control mode.
STOP/RES Stop/Reset key
Stop the running in the running state and reset the operation
in the fault state.
MF.K No function Reserved.
QUICK No function Reserved.
4.2 Viewing and Modifying Function Codes
The operation panel of the CS500 adopts three-level menu.
The three-level menu consists of function code group (Level I), function code (Level II),
and function code setting value (level III), as shown in the following figure.
