Chapter 5 Troubleshooting
5.1 Description of Fault Levels
The NICE3000
new
has almost 70 pieces of alarm information and protective functions. It monitors various
input signals, running conditions and feedback signals. If a fault occurs, the system implements the relevant
protective function and displays the fault code.
The controller is a complicated electronic control system and the displayed fault information is graded into
ve levels according to the severity. The faults of different levels are handled according to the following
table.
Table 5-1 Fault levels
Category Action Remarks
Level 1
1. Display the fault code.
2. Output the fault relay action command.
1A: The elevator running is not affected on any
condition.
Level 2
1. Display fault code.
2. Output the fault relay action command.
3. Continue normal running of the
elevator.
2A: The parallel/group control function is disabled.
2B: The door pre-open/re-leveling function is disabled.
Level 3
1. Display the fault code.
2. Output the fault relay action command.
3. Stop output and apply the brake
immediately after stop.
3A: In low-speed running, the elevator stops at special
deceleration rate, and cannot restart.
3B: In low-speed running, the elevator does not stop.
In normal-speed running, the elevator stops, and then
can start running at low speed after a delay of 3s.
Level 4
1. Display the fault code.
2. Output the fault relay action command.
3. In distance control, the elevator
decelerates to stop and cannot run
again.
4A: In low-speed running, the elevator stops under
special deceleration rate, and cannot restart.
4B: In low-speed running, the elevator does not stop.
In normal-speed running, the elevator stops, and then
can start running at low speed after a delay of 3s.
4C: In low-speed running, the elevator does not stop.
In normal-speed running, the elevator stops, and then
can start running at low speed after a delay of 3s.
Level 5
1. Display the fault code.
2. Output the fault relay action command.
3. The elevator stops immediately.
5A: In low-speed running, the elevator stops
immediately and cannot restart.
5B: In low-speed running, the elevator does not stop.
In normal-speed running, the elevator stops, and then
can start running at low speed after a delay of 3s.
