1 Product Information
1
1.7.3 CCB Board (MCTC-CCB)
The car call board (MCTC-CCB) is another interface between users and the control system. Each CCB
comprises 24 inputs and 22 outputs, including 16 oor buttons and 8 functional signals. The CCB mainly
collects button calls and outputs signals of the button call indicators. The need for 40-floor use can be
implemented through cascaded connection. CN2 is an input connector and CN1 is a cascaded output
connector.
Figure 1-2 Appearance, dimensions, and installation method of the CCB
1 2 3 4
1 2 3 4
1 2 3
4
1
2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1
2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
JP1 JP2 JP
3
JP4
JP5 JP6 JP7 JP8
JP9 JP10 JP11 JP12
JP13 JP14 JP15 JP16
JP17 JP18 JP19 JP20
JP21 JP22 JP23 JP24
CN1
Buzzer
MCTC-CCB
CN2
R2.5
158 148
69
79
Floor 1 Floor 2 Floor 3 Floor 4
Floor 5 Floor 6 Floor 7 Floor 8
Floor 9 Floor 10 Floor 11 Floor 12
Floor 13 Floor 14 Floor 15 Floor 16
Door open
Door
close
Door open
delay
Direct
travel ride
Attendant
Direction
change
Independent
running
Fire
emergency
Unit: mm
The following table describes the input and output terminals of the CCB.
