2 System Commissioning
2
2. Check that the conditions for shaft auto-tuning have been met.
1) The elevator is in the inspection state.
2) The elevator is at the leveling position of the bottom oor.
3) The down slow-down switch 1 signal input to the MCB is active.
4) The NICE3000
new
is not in the fault state. If there is a fault, press
STOP
RES
to reset the fault.
Note
When there are only two oors, the elevator needs to run to below the bottom
leveling position, that is, at least one leveling sensor is below the leveling plate.
This is the prerequisite for successful shaft auto-tuning.
3. Perform shaft auto-tuning.
When the preceding conditions are met, start shaft auto-tuning by using any of the following methods:
1) Set F1-11 to 3 on the operation panel.
2) Set F-7 to 1 on the keypad of the MCB.
After shaft auto-tuning starts, the elevator runs at the inspection speed set in F3-11 and stops after
reaching the leveling plate of the top oor. Then, the keypad on the MCB displays the present oor
number (top oor), indicating that shaft auto-tuning is successful.
If fault E35 is reported during the process, it indicates that shaft auto-tuning fails. You need to rectify
the fault according to the solution described in Chapter 5, and perform shaft auto-tuning again.
2.2.4 Door Machine Controller Commissioning
The procedure of door machine controller commissioning is as follows:
1. Check that F7-05 (Door open forbidden) is 0 (No).
2. Check whether the door machine controller wiring is correct and secure and that the power voltage is
proper.
3. Commission the door machine controller, and check whether the input and output of the door machine
controller are normal in terminal control mode.
1) Check that the door open/close output is normal:
Short BM/B1 on the CTB, and door 1 opens; short BM/B2, and door 1 closes. If the door acts
abnormally after you short BM/B1 or BM/B2 on the CTB, check:
a. Whether cable connection between the CTB and the door machine controller is correct
b. Whether the function setting of door open/close input terminals is correct
c. Whether door machine controller commissioning fails. If yes, perform commissioning again.
2) Check whether the door open/close limit signal feedback from the door machine controller is
normal.
Observe the X terminal signal indicators on the CTB and judge whether feedback from the door
machine controller is normal, according to the following table.
