- 68 -
3 System Functions
3
Related Parameters
Parameter No. Parameter Name Setting Range
F-8 Test function 7: UCMP manual detection
F3-24 Program function selection
1: Slip experiment
2: UCMP manual detection
F5-01 X1 function selection
01/33: Up leveling signal NO/NC
(MCTC-SCB-A/A1)
01: Up leveling signal NO (MCTC-SCB-C/D)
F5-03 X3 function selection
02/34: 02/34: Down leveling signal NO/NC (MCTC-SCB-A/A1)
02: Down leveling signal NO (MCTC-SCB-C/D)
F5-02 X2 function selection 03: Door zone signal NO
F5-08 X8 function selection 22: Shorting door lock circuit relay feedback NO
F5-30 Y5 function selection 03: Shorting door lock circuit relay output
The test procedure is as follows:
1. Switch the system to inspection state, and ensure that the elevator is in door zone with door lock
enabled.
2. Set F-8 on the keypad to 7 (or set F3-24 on the operating panel to 2), and āE88ā is displayed,
indicating the UCMP detection function is enabled. Disconnect the door lock circuit.
3. Hold down the inspection up or down button. The shorting door lock circuit relay outputs, shorting the
door lock; the elevator enters the inspection running state.
4. The elevator runs out of the door zone (door zone signal becomes invalid). The UCMP module
cancels door lock circuit shorting, and the system reports E65 (UCMP fault). The elevator stops
running.
Setting F-8 to 7 or F3-24 to 2 does not take effect if either of the conditions (in inspection
state, within door zone, door lock disabled) is not met.
F-8 or F3-24 automatically restores to the default value after a running or power failure.
In UCMP detection mode, the elevator accelerates in linear mode to the inspection speed
according to the acceleration rate set in F3-08.
E65 cannot be automatically reset, even after power-on and power-off. It can only be reset in
inspection state.
