Required Parts:
1x (#4) Swing Arm Assembly, Left 1x (#5) Swing Arm Assembly, Right
1x (#10) Handlebar, Left 1x (#11) Handlebar, Right
Installing Swing Arms
A.) Begin with the (#5) Swing Arm Assembly, Right
B.) Slide the (#5) Swing Arm Assembly, over the user right pivot shaft of the main
frame. C.) Attached Using:
1x (#167) Socket Cap Screw 1x (#46) Aluminum Cap
D.) Slide the (#7) Pedal Arm that is already attached to unit into the end of the
Swing Arm, labeled #9 in the exploded diagram.
E.) Attached using:
2x (#163) Button Head Allen Screw 2x (#135) Button Head Screw
2x (#164) Nut 2x (#162) Flat Washer
2x (#166) Flat Washer 2x (#154) Spring Washer
F.) Slide the (#4) Swing Arm Assembly, Left over the pivot shaft of the main frame.
G.) Attached Using:
1x (#167) Socket Cap Screw 1x (#46) Aluminum Cap
H.) Slide the (#6) Pedal Arm that is already attached to unit into the end of the
Swing Arm, labeled #8 in the exploded diagram.
I.) Attached using:
Installing Handlebars
A) Insert the (#10) Handlebar L into the open end of the (#4) Swing Arm Assembly, Left
B) Insert the (#11) Handlebar R into the open end of the (#5) Swing Arm Assembly Right
To Next Page
