Step 6 Installing the Child Safety Lock
Required Hardware:
4x (#106) Allen Head Screw
Required Parts:
1x (#30) Child Safety Lock
Attaching the Child Safety Lock:
A) The Child Safety Lock will be attached on the User RIGHT of the bottom rail.
Locate the four preset threaded holes on the rail
B) Be sure to align the Child Safety Lock with the cable and clip towards the front of
the unit
C) Attach Using:
4x (#106) Allen Head Screw
D.) Clip the Child Safety Lock into the hook located under the foot pedal. This will lock the
system linkages.
E.) Before Use; remove the clip from the loop and clip to the holding loop on the safety lock
itself.
NOTE: Ensure that the Child Safety Lock does not come into contact with the bottom of the pedal in
the lowest position. This will cause interference with each pedal rotation.
